Description
Stego Filter Fan Plus FPI intake fan, side mount, 100 CFM, 48 VDC operating voltage, G3 (coarse) filter mat, NEMA 12, indoor use only, 6.93 x 6.93in enclosure cutout, RAL 7035 light gray.
Brand: Stego
Series: Filter Fan Plus FPI
Airflow Direction: Intake
Item: Fan
Mounting: Side
With Air Flaps: No
Filter Media: G3 (coarse) filter mat
Free Airflow: 100 CFM
Airflow with Grill and Filter(s): 87 CFM
Operating Voltage: 48 VDC
Power Consumption: 12W
Current Draw: 250 mA
Electrical Connection: 3-pole clamp for AWG 14 wire, 7.1 in-lb maximum clamping torque
Maximum Static Pressure: 122Pa
Operating Temperature: -13 to 158 deg F
Average Noise Level: 63 dBA
NEMA Rating: 12
Application: Indoor use only
IP Rating: IP54
Enclosure Cutout: 6.93 x 6.93in
Color: RAL 7035 light gray
Includes: Optional mounting screws
Additional Information: Purchase exhaust grille separately
Series: Filter Fan Plus FPI
Airflow Direction: Intake
Item: Fan
Mounting: Side
With Air Flaps: No
Filter Media: G3 (coarse) filter mat
Free Airflow: 100 CFM
Airflow with Grill and Filter(s): 87 CFM
Operating Voltage: 48 VDC
Power Consumption: 12W
Current Draw: 250 mA
Electrical Connection: 3-pole clamp for AWG 14 wire, 7.1 in-lb maximum clamping torque
Maximum Static Pressure: 122Pa
Operating Temperature: -13 to 158 deg F
Average Noise Level: 63 dBA
NEMA Rating: 12
Application: Indoor use only
IP Rating: IP54
Enclosure Cutout: 6.93 x 6.93in
Color: RAL 7035 light gray
Includes: Optional mounting screws
Additional Information: Purchase exhaust grille separately
