Description
The LAPP SKINTOP® MS-SC NPT is uniquely designed to address EMI concerns with its simplified grounding feature. In a few easy steps the cable is grounded, strain relieved, and sealed from moisture and dust in accordance with IP68. The cable glands’ contact springs establish a continuous electrical path from the shield of the cable to the equipment ground, creating a secure shield connection.
| MANUFACTURER LAPP |
MANUFACTURER PART NUMBER 53112950 |
SERIES SKINTOP® MS-SC |
| THREAD TYPE NPT |
THREAD SIZE 1-1/4 |
THREAD LENGTH (IN) 0.669 |
| BODY MATERIAL Nickel-plated brass |
COLOR Metallic |
CLAMPING RANGE (IN) 0.748 – 1.103 |
| CLAMPING RANGE (MM) 19 – 28 |
OVERALL LENGTH (IN) 2.264 |
BUSHING CR |
| INSERT Polyamide |
LOCKNUT Not Included |
WRENCHING FLATS (IN) 1.773 |
| DYNAMIC TEMPERATURE RATING -13°F to +212°F -25°C to +100°C |
STATIC TEMPERATURE RATING -40°F to +212°F -40°C to +100°C |
IP RATING IP68 |
| STANDARDS/APPROVALS UL Approved |
