New Release DMR-0N-1A

AutomationDirect photoelectric sensor, tubular, threaded, metal housing, through-beam receiver, 4m sensing distance, 10-30 VDC operating voltage, selectable light-on/dark-on, NPN, 4-wire, pigtail.

Brand: AutomationDirect
Item: Photoelectric sensor
Shape: Tubular
Barrel Type: Threaded
Housing Size: 12mm diameter x 55mm body
IP Rating: IP67
Application: Standard duty
Housing Material: Metal
Sensing Method: Through-beam receiver
Operating Voltage: 10-30 VDC
Number of Wires: 4
Switching Output: NPN
Sensing Distance: 4m
Operation Mode: Selectable light-on/dark-on
Switching Frequency: 250 Hz
Cable Length: 6.5ft/2m
Connection: Pigtail
Conductor Size: 26 AWG
Includes: Mounting hardware
